Flexible Duct Sag Prevention Support Spacing Rules

Flexible Duct Sag Prevention Support Spacing Rules When SMACNA published the third edition of its HVAC Duct Construction Standards, it fixed a number many installers still get wrong: 4 feet. That is the maximum permitted unsupported horizontal span for flexible duct sized 12 inches in diameter or larger, and the number gets tighter for smaller diameters. A properly supported flex run keeps its listed pressure drop of roughly 0.05 inches of water column per 100 feet at 600 feet-per-minute velocity. A neglected one, sagging in the belly between two truss chords, can lose 30 to 60 percent of its effective airflow before the homeowner ever notices the second-floor bedroom running warm. The wire helix inside modern R-8 flex is engineered for tension in a straight line, not for bearing its own insulated weight over long unsupported spans. Support spacing is not a cosmetic concern. It is the single detail that separates a system that delivers its Manual J load from one that cannot. ...
